Sistem 3D pentru aplicatii de Fizica

EXERCISES AND PRACTICAL POSSIBILITIES

Practices to be done with the Thermodynamics Study application:

1.-   Programming and applications of a robot arm.

Laboratory practices in one dimension:

2.-   Calibration of the temperature sensors.

3.-   Conduction in one dimension.

4.-   Determination of the thermal conductivity “k”.

5.-   Conduction through a compound bar.

6.-   Determination of the thermal conductivity, k, of the stainless steel.

7.-   Determination of the thermal contact resistance R tc.

8.-   Insulation effect.

Laboratory practices:

9.-   Introduction.

10.- Temperature distribution on two-dimensional system.

11.- Determination of the thermal conductivity in two-dimensional system.

12.- Heat flow in a two-dimensional system.

IMPORTANT: The  teacher can use his own elements,  so these  practical possibilities are NEARLY UNLIMITED


Producător: Edibon

Model: EFAC

Cod: c6e953a4cb42

Preţ, fără TVA: La cerere

Distribuie

Telefon: 0744.594.794 / 0251.417.664

E-mail: tehnic@aparatura-laboratoare.ro

1 Sets required for each application:

      We offer some Sets of components for doing the main exercises and practices, but THE UNIT IS OPEN to use many other elements that can be chosen by the teacher.

FCE. Set for Electrical Fields application:

This application can be done by using just the following:

-Common items for all applications:

1) FUB. Base structure and Robot.

2) EFAC/CIB. Control Interface Box.

3) DAB. Data Acquisition Board.

-Set for this particular application, including these items:

a) Sensor:

Sensor of Electric Field. It is a probe capable of measuring the potential created by any distribution of loads. It consists  on a conductor wire that measures the reference and the point where it is located.

b) Elements:

A nickel-plated conductor sphere with diameter of 100 mm.

Conductor coil sheets of 280 x 240 mm (2 units).  Conductor coil sheets of 100 x 280 mm (2 units).

A nickel-plated sphere with insulating rod.

Several conductor plates.

Tank.

Red conductor cable with banana crocodile.

Black conductor cable with banana crocodile.

Black cables (2 units) with bananas at the ends.  Red cables (2 units) with bananas at the ends.

The teacher can use any element that creates ELECTRICAL FIELDS, so the UNIT IS OPEN and can do MANY OTHER EXPERIMENTS.

c) Computer Control Software:

Computer Control+Data Acquisition+Data Management Software for Electrical Fields application.

Compatible with actual Windows operating systems. Graphic and intuitive simulation of the process in screen.

Compatible with the industry standards.

Registration and visualization of all process variables in an automatic and simultaneously way.

Flexible and open software, developed with actual windows graphic systems, acting simultaneously on all process parameters.

Management, processing, comparison and storage of data.

Sampling velocity up to 250,000 data per second.

Student calibration system for all sensors involved in the process.

It allows the registration of the alarms state and the graphic representation in real time. Comparative analysis of the obtained data, after the process and modification of the conditions during the process.

Open software, allowing to the teacher to modify texts, instructions. Teacher’s and student’s passwords to facilitate the teacher’s control on the student, and allowing the access at different work levels.

This unit allows that the 30 students of the classroom can visualize simultaneously all results  and manipulation of the unit, during the process,  by using a projector.

EXERCISES AND PRACTICAL POSSIBILITIES

Practices to be done with the Thermodynamics Study application:

1.-   Programming and applications of a robot arm.

Laboratory practices in one dimension:

2.-   Calibration of the temperature sensors.

3.-   Conduction in one dimension.

4.-   Determination of the thermal conductivity “k”.

5.-   Conduction through a compound bar.

6.-   Determination of the thermal conductivity, k, of the stainless steel.

7.-   Determination of the thermal contact resistance R tc.

8.-   Insulation effect.

Laboratory practices:

9.-   Introduction.

10.- Temperature distribution on two-dimensional system.

11.- Determination of the thermal conductivity in two-dimensional system.

12.- Heat flow in a two-dimensional system.

IMPORTANT: The  teacher can use his own elements,  so these  practical possibilities are NEARLY UNLIMITED
