Aparat pentru determinarea stabilitatii oxidarii grasimilor lubrifiante prin metoda vasului de oxigen sub presiune

The apparatus consists of a benchtop case containing an aluminium block and the electronics: a touch screen interface on the front permits to control the equipment. Temperature and pressure data are graphically shown and can be retrieved or printed: the software comprehends also a diagnostic and calibration routine. Vessels are equipped with a pressure transducer and a quick connect cable for the connection to the instrument: an oxygen line consisting of a flexible tube with valve and gage permits loading operations.


Producător: Scavini

Model: ASTM D 942 - IP 142

Cod: AD0942-600

Preţ, fără TVA: La cerere

Distribuie

Telefon: 0744.594.794 / 0251.417.664

E-mail: tehnic@aparatura-laboratoare.ro

- Enamel finished aluminium and steel case, benchtop version.

- Dry block heater, two, four or six-place.

- 8.4” touch screen color interface that permits to set block temperature, start/stop tests, enter sample data, diagnose and calibrate temperature and pressure sensor. Temperature digital display with 0.1°C accuracy and +/- 0.1°C regulation accuracy connected to Pt100 RTD. Selectable kPa/psi pressure indicators with 0.1 kPa/psi accuracy: high precision electronic pressure sensors 0 to 2000 kPa scale with 0.1% f.s. accuracy.

- Working range: from ambient to 120°C. Regulation accuracy: ± 0.1°C.

- Stainless steel cartridge heaters, SSR controlled.

- Independent safety device against overheating.

- Oxygen distributor with gage and flexible tube with quick connects for rapid filling of the vessels.

- User friendly graphical software complete with diagnose and calibration routine.

- CE marked.



Model

ASTM D 942

accuracy

+/- 0.1°C

pressure sensors

0 to 2000 kPa

pressure sensors accuracy

0.1% f.s.

Working range:

from ambient to 120°C

Regulation accuracy:

± 0.1°C

Interface

N° 2 USB ports, n° 1 RS-232 interface and n° 1 Ethernet port on the back panel for the connection to printers or laboratory network.



- For 220 V/50 Hz connections:

2000 W max power consumption.

Oxidation vessel complete with valve, bursting disk, pressure transducer head cable and connector

AD0942-A00

Stainless steel dish holder

AD0942-A01

Printer

PRN01

PT100 simulator

CAL001

Official Certificate for Pt100 simulator

CAL003

Consumbles



Gasket for vessel

AD0942-C00

Glass sample container

AD0942-C01

ASTM 22C thermometer (+95°C/+103°C)

TA022C-N00
